CuNi Copper Nickel CuNi1 Alloy Electric Heating Ribbon Wire With Low Resistance

Product Categories
Changzhou Victory Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

CuNi Copper Nickel CuNi1 Alloy Electric Heating Ribbon Wire With Low Resistance

Brand Name : Victory

Model Number : CuNi23、CuNi30、CuNi34、6J8、6J11

Place of Origin : China

MOQ : 5

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 300 tons per month

Delivery Time : 7-20 days

Packaging Details : Spool package with Carton box, Coil package with polybag

Certification : CE,ROHS,ISO 9001

Product Name : CuNi Wire

Nickel(Min) : 44%

Resistivity : 0.5

Tensile Strength : 420 MPA

Density : 8.9 g/cm3

Application : Heating, Resistivity

Condition : Hard / Soft

Sureface : Bright

Maximum Temperature : 420℃

Melting Point : 1100℃

Contact Now

Cuni is a type of resistance alloy, which is made up of copper and nickel as the main components. It has a low temperature coefficient of resistance (TCR), and a wide operating temperature range. It has good properities on mechanical working, low electric resistance, good heat-resistant and corrosion-resistant, easy to be processed and lead welded. It is used to make the key components in the thermal overload relay, low resistance thermal circuit breaker, and the electrical appliances. It is also an important material for electrical heating cable.

Cu-Ni Alloy: CuNi1,CuNi2,CuNi6,CuNi8, CuNi10, CuNi14, CuNi19,CuNi23,CuNi30,CuNi34, CuNi44
NC003, NC005, NC010, NC012, NC015, NC020, NC025, NC030, NC035, NC040, NC050
We can supply type of : wire, ribbon,strip, customized furnace spring wire/strip
Cold Drawing Wire: DIA 0.03m-8.0mm
Hot Rolled Rod / Bar: DIA 8.0mm-50.0mm
Cold Rolled Ribbon/Strip: (0.05mm-0.35mm) *(0.5-6.0)mm

Properties/ Material
Resistivity (200C μΩ.m)
Max. Working Temperature(C)
Tensile Strength (Mpa)
Melting Point
Density(g/cm3)
NC003(CuNi1)
0.03
200
210
1085
8.9
NC005(CuNi2)
0.05
200
220
1090
8.9
NC010(CuNi6)
0.1
220
250
1095
8.9
NC012(CuNi8)
0.12
250
270
1097
8.9
NC015(CuNi10)
0.15
250
290
1100
8.9
NC020(CuNi14)
0.2
300
310
1115
8.9
NC025(CuNi19)
0.25
300
340
1135
8.9
NC030(CuNi23)
0.3
300
350
1150
8.9
NC035(CuNi30)
0.35
350
400
1170
8.9
NC040(CuNi34)
0.4
350
400
1180
8.9
NC050(CuNi44)
0.5
400
420
1200
8.9

CuNi Copper Nickel CuNi1 Alloy Electric Heating Ribbon Wire With Low Resistance
Shape
Size(mm)
Wire
0.05-7.5
Rod
8-50
Ribbon
(0.05-0.35)*(0.5-6.0)
Strip
(0.5-2.5)*(5-40)

CuNi Copper Nickel CuNi1 Alloy Electric Heating Ribbon Wire With Low Resistance CuNi Copper Nickel CuNi1 Alloy Electric Heating Ribbon Wire With Low Resistance
